Build a config modifier schema

Different sites expect different things. You can hardcode fields and values so that your connection always gets the required data. For example, you might expect a certain document ID type or sending facility code in every message.

Scenario: You’re receiving a PatientAdmin data model from your connection.

Problem: Your connection (i.e., source system) isn’t populating the MSH.4 (i.e., FacilityCode) segment. Your system expects the sending facility code in Meta.FacilityCode.

Goal: Populate the FacilityCode with a specific value. In this case, you know the code should always be acme-123.

Input payload: In this input payload, you see the facility code is missing from the Meta object.

1
{
2
  "Meta": {
3
    "DataModel": "PatientAdmin",
4
    "EventType": "Arrival"
5
  }
6
}

Selector: First, define where you want the config modifier to populate a value.

1
$.Meta.FacilityCode

Schema: Next, build your schema to hardcode the FacilityCode value on each PatientAdmin message from this source feed with this keyword:

• constant: Since you want to output the same value on each message, you need to use the constant keyword. Learn about constant.

1
constant: acme-123

Output payload: This config modifier would result in the hardcoded FacilityCode value in the Meta object.

1
{
2
  "Meta": {
3
    "DataModel": "PatientAdmin",
4
    "EventType": "Arrival",
5
    "FacilityCode": "acme-123"
6
  }
7
}

Different sites configure their messages differently, so data might be found in unusual places. Redox base configs account for most of these variations. But if a value is missing from the segment you expect, you could write a config modifier to pull that value from another segment. For example, your connection sends the time the visit starts in an unexpected segment.

Scenario: You receive a Scheduling.New message from your connection (i.e., the source system).

Problem: Your system expects VisitDateTime to be populated with the time the visit starts, but in testing, you notice you’re receiving the time the visit ends. Also, the value isn’t in your preferred date-time format.

Goal: Populate the VisitDateTime from SCH 11.1 (the time the visit starts) instead of SCH.11.4 (the time the visit ends).

Input payload: In this input payload, the desired start time (20240603165602) is located at SCH.11[0].1.1.

1
{
2
  "SCH": {
3
    ...
4
    "11": [
5
      {
6
        "1": {
7
          "1": "20240603165602"
8
        },
9
        "2": {
10
          "1": ""
11
        },
12
        "3": "",
13
        "4": {
14
          "1": "20240603175602"
15
        }
16
      }
17
    ]
18
  }
19
}

Selector: First, define where you want the config modifier to populate a value.

1
$.Visit.VisitDateTime

Schema: Next, build your schema to retrieve the value at SCH 11.1 and reformat it with these keywords:

• use: You need to access the initial HL7v2 payload, which is outside the scope of the selector path. That means you need to include use. Learn about use.
• get: You need to define where to get the value from to populate the selector path.
• plugin: You need the date-time value to be in ISO-8601 format, so you need to use a plugin to reformat. Learn about plugin.
  • name: Use the date-time plugin to format the value.
  • action: To reformat the incoming value into ISO-8601, use parse.
  • parameters.standard: Identifies the current format of the incoming value, which is in HL7 format.

1
use: initialPayload
2
get: SCH.11[0].1.1
3
plugin:
4
   name: date-time
5
   action: parse
6
   parameters:
7
      standard: HL7

Output payload: This config modifier results in using the desired start time in the correct format.

1
{
2
  ...
3
  "Visit": {
4
    ...
5
    "VisitDateTime": "2024-06-03T16:56:02.000Z"
6
  }
7
 }

Sometimes a site is inconsistent with their own message formatting. A site might populate a value in one field in some messages but leave it blank or populate a different field for other messages. This can happen if your connection handles IDs and codes differently based on the visit or order type.

Scenario: Your connection sends a Visit ID in one segment for some types of visits, but in a different segment for other types of visits.

Problem: Sometimes the input payload looks like Example 1, and sometimes it looks like Example 2. Redox handles the visit ID correctly for Example 1. But in Example 2, Redox uses null for the visit ID because it’s not where we expect.

Goal: Populate visit ID regardless of the visit type.

Input payload: These input payloads show the different locations visit ID might be.

1
{
2
  ...
3
  "PV1": {
4
    ...
5
    "19": {
6
      "1": "1234"
7
    }
8
  }
9
}

1
{
2
  ...
3
  "PV1": {
4
    ...
5
    "50": {
6
      "1": "1234"
7
    }
8
  }
9
}

Selector: First, define where you want the config modifier to output a value.

1
$.Visit.VisitNumber

Schema: Next, build your schema to look for visit ID depending on whether PV1.19.1 is populated or not with these keywords:

• use: You need to access the initial HL7v2 payload, which is outside the scope of the selector path. That means you need to include use. Learn about use.
• if: The action to take is a conditional decision. That means you need to include if to define the logic for each condition. Learn about if.
  • operator: First, Redox should check that the value exists, so you should enter all. Learn about operator.
  • terms: Next, Redox should check whether PV1.19.1 exists, so that value is our singular term. Learn about terms.
    • get: Define where to get the value from to populate the selector path. Learn about get.
  • then: Define what should happen when the if scenario is true. In this case, use PV1.19.1 if it exists. Learn about then.
    • get: If PV1.19.1. exists, retrieve its value. Learn about get.
  • else: Define what should happen when the if scenario isn’t true. In this case, use PV1.50.1 if PV1.19.1 doesn’t exist. Learn about else.

1
use: initialPayload
2
if:
3
  operator: all
4
  terms:
5
    - get: PV1.19.1
6
  then:
7
    get: PV1.19.1
8
  else:
9
    get: PV1.50.1

Output payload: This config modifier results in populating the visit ID, regardless of whether PV1.19.1 is populated or not.

1
{
2
  ...
3
  "Visit": {
4
    ...
5
    "VisitNumber": "1234"
6
  }
7
}

Sometimes a site can’t parse or receive data you have in its existing format. If the data format is incompatible, it might return an error or the site won’t receive important data.

Scenario: Your connection doesn’t accept underscores for the Observation codes under OBX.3.1.

Problem: We can’t simply use the text plugin for replace where we replace all the underscores with an empty string because it will return as undefined.

Goal: Remove the underscores under every Observation code (OBX.3.1)

Input payload: In this input payload, you see the text string with extra underscore (_) characters.

1
"PATIENT_RESULT": [
2
    {
3
      "ORDER_OBSERVATION": [
4
        {
5
          ...
6
          "OBSERVATION": [
7
            {
8
              ...
9
              "OBX": {
10
                ...
11
                "3": {
12
                  "1": "STD_DEV_SMBG",
13
                  "2": "Standard deviation across SMBG values in 14 days",
14
                  "3": null
15
                }
16
              }
17
            }
18
          ]
19
        }
20
      ]
21
    }
22
  ]

Selector: First, define which text string you want to remove characters from.

1
$.PATIENT_RESULT[*].ORDER_OBSERVATION[*].OBSERVATION[*].OBX.3.1

Schema: Next, build your schema to look for the unnecessary characters and remove from the text string with these keywords:

• pipe: You need to use the output of the first keyword action as the input of the second. Learn about pipe.
• plugin: Plugins are common actions you can leverage for your schema.
  • text-split: The text plugin is for manipulating string values. The split action removes the underscore (_) characters. Learn about the text plugin.
  • array-join: The array plugin is for manipulating array values. The join action combines the text string that was split after removing the underscore (_) characters. Learn about the array plugin.

1
pipe:
2
  - plugin:
3
      name: text
4
      action: split
5
      parameters:
6
        separator: _
7
  - plugin:
8
      name: array
9
      action: join
10
      parameters:
11
        separator: ''

Output payload: This config modifier results in removing the extra underscore (_) characters from OBX.3.1.

1
"PATIENT_RESULT": [
2
    {
3
      "ORDER_OBSERVATION": [
4
        {
5
          ...
6
          "OBSERVATION": [
7
            {
8
              ...
9
              "OBX": {
10
                ...
11
                "3": {
12
                  "1": "STDDEVSMBG",
13
                  "2": "Standard deviation across SMBG values in 14 days",
14
                  "3": null
15
                }
16
              }
17
            }
18
          ]
19
        }
20
      ]
21
    }
22
  ]
